Configuring a DHCPv6 PD Server

Procedure

1. Choose Network > DHCP Server > Settings.
2. Click Add.



3. Set the following basic DHCPv6 PD server parameters.

   Parameter	Description
   Interface Name	Name of the interface on which the DHCPv6 PD server function is configured. The interface must be an existing physical interface, and its Connection Type must be set to Static IP.
   Type	Protocol type on the interface: IPv4: enables DHCPv4. IPv6: enables DHCPv6. Select IPv6 in this example.
   Service Type	Enable server service on this interface.
   (Optional)Primary DNS Server	Primary DNS PDserver address to be assigned to a DHCPv6 client.
   (Optional)Secondary DNS Server	Secondary DNS PDserver address to be assigned to a DHCPv6 client.

4. Set parameters for the address pool.
   1. Click Add in Delegated Prefix. In the dialog box, click OK.
   2. Set parameters for the DHCPv6 PD address pool.

      • Setting basic parameters of the prefix pool

        Parameter	Description
        Type	Type of a DHCPv6 PD prefix pool. Select Prefix for a DHCPv6 PD delegation prefix pool.
        Prefix	IPv6 prefix address/prefix length.
        Delegation Prefix Length	Address prefix length. The DHCPv6 PD client divides the prefix into subnet segments based on Delegation Prefix Length. The length of a prefix to be assigned must be longer than or equal to the length of Prefix.
        Lease Duration	Lease duration of the prefix bound to the IPv6 address pool. Use Unlimited or set a specific lease period.

      • (optional) Statically bind a DHCPv6 prefix to a DUID.

        1. Click Add in Static Prefix Binding. In the dialog box, click OK.

        2. Set the static prefix and DUID.

           Parameter	Description
           Prefix	IPv6 prefix. An assigned IPv6 prefix is reserved for the client and cannot be assigned to another client.
           DHCPv6 Client DUID	Client DUID that the DHCPv6 PD server uses to identify a client.
           Lease Duration	Lease duration of the bound entry. Select Unlimited or set a specific lease period.

        3. Click OK.

   3. Click OK.
5. Optional: Set the following advanced DHCPv6 PD server parameters.

   Parameter	Description
   Domain Name	DNS suffix that a DHCPv6 PD server assigns to a DHCPv6 client.
   SNTP Server	SNTP server address that a DHCPv6 PD server assigns to a DHCPv6 client.
   SIP Server	SIP server address that a DHCPv6 PD server assigns to a DHCPv6 client.

6. Click Apply.

   Repeat previous operations to configure the DHCPv6 PD server function on multiple interfaces.
